Below is my lighting column published in the October issue of tED Magazine. Reprinted with permission.

Strategies Unlimited has forecasted that by 2022, LED luminaires will achieve a 60 percent share of global luminaire shipments.

In the U.S., three major manufacturers of indoor LED luminaires say LED already constitutes a majority of their indoor luminaire sales.

“The rate of change in the lighting market is unprecedented,” says Jerry Mix, CEO, Finelite, Inc. “Five years ago, LED was suspect, incandescent was standard for residential applications, and fluorescent dominated commercial lighting. Today, incandescent is out, and fluorescent is being overtaken by LED.”

“We see legacy sources being almost completely eliminated from our business within the next few years, speaking strongly to the level of market share and adoption,” says Imran Ahmad, General Manager, Architectural Lighting, Eaton’s Lighting Division.

Martin Werr, Director of Product Innovation, Hubbell Lighting, believes a majority of LED retrofits now involve new luminaires. “A significant percentage of customers, however, accept half-measures through the use of LED replacement lamps in an effort to mitigate first costs,” he adds. “Typically, however, these result in less-than-ideal performance compromises.” An exception, he points out, being luminaire retrofit kits.

Mix, Ahmad and Werr identified five key trends in indoor luminaires that reflect innovation and are driving category growth.

LED luminaires are getting sleeker. LED sources are highly compact and reduce the distance required between the source and optics. As these sources become more efficacious—producing more lumens per watt—fewer sources are needed, which reduces the size of the heat sinking and housing. As a result, the early clunky LED luminaires are giving way to the current generation of sleek products. While sleeker, luminaires are not necessarily smaller, as they are often designed to replace existing luminaires. However, the smaller light source enables new form factors now being explored.

Mix calls this “tailored lighting”—luminaires that follow architectural forms, available in quick-shipped custom configurations. “Demand for the design freedom of tailored lengths and configurations is growing exponentially,” he says. “Tailored lighting—lines of light defined by architecture—has seized the imagination of architects and lighting designers and changed the expectations of owners and tenants.” Mix sees lighting as becoming defined by architecture and a more permanent part of the built environment, similar to windows, doors and walls.

While most luminaires are highly integrated appliances, a growing number of manufacturers are offering serviceable luminaires, though these features may impose a cost premium in exchange for the added value. “For most applications such as recessed troffers and high bays, specifiers and end-users should insist on light engines, drivers and optics that can be replaced or upgraded from below,” says Werr. “Despite the implication from some lower-tier manufacturers, LEDs do not last forever, and even if they did, they are continuously improving. Responsible manufacturers provide the ability to upgrade luminaires as more energy-efficient light engines become available.”

LED lighting is available in custom configurations and lengths, allowing lines of light to be integrated into the built environment. (Amenta Emma Architects Office. Photo by Robert Benson.)

LED lighting is available in custom configurations and lengths, allowing lines of light to be integrated into the built environment. (Amenta Emma Architects Office. Photo by Robert Benson.)

LED sources and optics have become integrated. As highly compact, directional point sources that produce very little radiated heat, LEDs offer the ability to attach optics directly to the source. This promotes very high optical efficiency (90-95 percent) while enabling light to be placed in precise patterns, improving application efficiency.

“Given that LEDs deliver flux within a narrower zone than traditional sources, LED optical systems are much more efficient since much less light is wasted,” says Ahmad. “Over time, we have seen optical systems evolve by getting smaller, more efficient and more precise.”

New optical approaches include total internal reflection (TIR) lenses, prismatic films and light guides. For tunable-white lighting, a diffusion film of frosted internal optical elements may be used. For architectural visual-comfort applications, edge-lit panels are trending.

Lighting is increasingly customizable. Traditional lighting is typically specified in standardized lumen packages and form factors, designed in more-or-less standardized layouts, and not very controlled. In contrast, LED lighting can be specified with drivers programmed across a wide range of lumen and wattage packages, which allows light levels and power to be tuned to individual project needs.

Good controllability is broadening application of lighting controls. LED lighting features instant-ON (with negligible depreciation in source life), inherent compatibility with intelligent controls, and dimming as a standard or standard option for the large majority of luminaires. Coupled with the miniaturization of sensors and advances in radio-frequency wireless communication, many luminaires are now being packaged with onboard sensors and wireless networked lighting control. This facilities greater energy savings, flexibility and potentially collection of data.

“The single biggest trend is the inclusion of dimming capability—once a luxury upcharge for fluorescent and impossible for HID,” says Werr. “Those in the market would be wise to choose a manufacturer that offers products with dimming capability at no additional cost. An additional benefit is the trend toward smart sensing in which each fixture may have integral occupancy/vacancy sensing, daylight harvesting or both.”

This luminaire combines OLED and LED light sources in the same luminaire, producing comfortable direct lighting via the OLED and precisely controlled uplight (the primary source of illumination) via LEDs. Image courtesy of Peerless Lighting (Acuity Brands).

This luminaire combines OLED and LED light sources in the same luminaire, producing comfortable direct lighting via the OLED and precisely controlled uplight (the primary source of illumination) via LEDs. Image courtesy of Peerless Lighting (Acuity Brands).



Luminaires now offer ability to tune shade of white light.
LED luminaires are available that allow color output to be adjusted automatically or manually. The major options include dim-to-warm, full-color-tuning and tunable-white products. This has allowed greater LED penetration while opening new applications and joining the growing conversation about lighting that supports circadian health. LEDs can also be designed with customized spectra for specialized applications such as horticultural lighting.

“There’s no doubt that demand for tunable white light, circadian design and individualized control over color and intensity is rising,” Mix says. “As we gain a better understanding of the impact of the color of light on health and wellness, demand for this technology will accelerate.”

These trends will strengthen in the future. With performance and reliability increasing while costs decline, the future will see these trends accelerate toward an LED future. Meanwhile, new software and infrastructure will promote luminaires equipped with additional sensors that enable the collection of data that can improve business operations.

“In the future, luminaires will be more intelligent and will be a primary vehicle for receiving and delivering meaningful data to the owner and/or occupant of the space,” Ahmad says. “Intelligent features will range from wireless communication, occupancy sensing, heat sensing, daylight sensing and color changing, and will be built in for a relatively low cost compared to today. The next frontier of lighting will be the development of software tools and applications that help clients run their businesses better.”
